Category: M2M componets

Radiation Patterns and Total Radiated Power (TRP) tested yourself

Turn table and special antenna to measure radiation pattern

For a few bucks you can get such a Radiation Measurement System (RMS) to measure Radiation Patterns and Total Radiated Power (TRP) from a 3-axis rotation of your wireless IoT / M2M application. While Radiation Patterns and Total Radiated Power (TRP) is usually measured in an anechoic chamber to avoid reflections to affect the measurement, […]

Which embedded antenna to select for your LPWAN / NB-IoT module?

25x25x4 mm ceramic patch antenna for LPWAN

Embedded LPWAN & NB-IoT antenna consideration On first quick look the choosing of the right integrated antenna for LPWAN & NB-IoT looks easy. In comparison to the large number of LTE bands the selection is simple because LPWAN (e.g. LoRaWAN, Sigfox, Weightless N) and NB-IoT (EC-GSM and NB-IoT) are on 900 MHz. There is no […]

Which embedded LTE antenna to select for your LTE module?

LTE chip antenna - SMT

Embedded LTE antenna consideration Choosing the right integrated LTE antenna is not easy. The large number of LTE bands makes the construction of integrated LTE antennas more complex. All that glitters is not gold. You have to look closely at the data sheet of the LTE antenna. The lowest LTE frequency is 698 MHz. The […]

WyzBee – your IoT enabler

WyzBee board

WyzBee – your IoT enabler The WyzBee board of Redpine Signals includes a wireless module providing Wi-Fi, Bluetooth 4.1, and ZigBee connectivity. Moreover it holds a six-axis inertial sensors, an infra-red receiver, a debug port, push-buttons, LEDs, USB ports, and expansion connector. Last but not least there is a Dual Core MCU with memory, wired […]

Hospital for Antennas – Our third IoT M2M outpatient – the magnetic mount cellular antenna

Magnetic mount cellular antenna on metal plate

Our third patient has a popular name. The manufacturers have called it the magnetic mount antenna. Further details about the third mobile antenna patient are given in the test below. Here are the medical records of the cellular magnetic mount antenna: Frequency bands: GSM 850/900 MHz, GSM 1800 / 1900 MHz, UMTS 2100 Frequency range: […]

Hospital for Antennas – Our second IoT M2M out-patient – cellular stubby antenna

Stubby cellular antenna with right angle SMA

Our second patient has a name as well. The manufacturers have called it the cellular stubby antenna. Further details about the second mobile antenna patient are given in the test below. Here are the medical records of the cellular stubby antenna: Frequency bands: GSM 850/900 MHz, GSM 1800 / 1900 MHz, UMTS 2100 Frequency range: […]

Hospital for Antennas – Our first IoT M2M out-patient

Penta band PCB antenna 40x15x0.4 mm

Our patient has a name. The manufacturers have called it the Penta-band PCB antenna. More details about the first mobile antenna patient are revealed in the test below. Here are the medical records of the Penta-band PCB antenna: Frequency bands: GSM 850/900 MHz, GSM 1800 / 1900 MHz, UMTS 2100 Frequency range: 824 – 960 […]
